Protek 840 hand held oscilloscope 40MHZ dso/dmm
Protek 840 Hand Held Oscilloscope 40MHz DSO/DMM ! NIB
Protek 840 Hand Held Oscilloscope 40MHz, DSO/DMM, 200MS/s sampling rate single channel and 100MS per channel in dual channel, 20 automatic waveform Measurements, self test and Self calibration, 125KB record length for each channel, USB interface (840 Protek840 Protek-840)
BRAND NEW IN FACTORY SEALED BOX. NEVER OPENED!!!
Model 840F has USB Flash Memory
Built in High accuracy 6000 count True RMS DMM
200MS/s sampling rate single channel and 100MS per channel in dual channel
20 automatic waveform Measurements
Self test and Self calibration
125KB record length for each channel
USB interface, cable and Software Included
High Resolution 320x 240 pixel Monochrome LCD
Edge/Pulse width, TV/Pattern and Delay trigger modes
Built in High accuracy 6000 count True RMS DMM
200MS/s sampling rate single channel and 100MS per channel in dual channel
20 automatic waveform Measurements
Self test and Self calibration
125KB record length for each channel
USB interface and optional flash memory port
High Resolution 320x 240 pixel Monochrome LCD
Edge/Pulse width, TV/Pattern and Delay trigger modes
Sensitivity 5mV to100V/div (in a 1,2,5 sequence)
Max. Input Voltage 300V DC or AC peak
Horizontal Sweep Rate 10ns/Div to 50s/Div
Acquisition System Acquisition Modes Sample, Peak detect, Envelope, Average
Sampling Real Time and Equivalent
Sample Rates 200MS/s single channel
100MS/s per channel Dual channel
Waveform Interpolation Dot, Linear, Sine, and Pulse
Trigger Sensitivity 0.5 Div (DC to 5MHz)
Trigger Types Edge, Pulse width, Video
Coupling AC, DC HF-Reject, LF-Reject, Noise Reject
Modes Normal, Single, Roll, Auto
Trigger Level Range ±20 Div from the center of the screen
Trigger Level Accuracy ±0.4 Div
Video Trigger Video Trigger sensitivity 0.7 Div
Measurements Types P-P, Max, Amplitude, Top, Base, Pos/Neg over shoot, Pre-shoot, RMS, Mean, One cycle mean, Freq., Period, ±Width, ±Duty cycle, Rise/Fall time, Delay and Phase shift
Math Operations CHA+CHB, CHA-CHB, CHB-CHA, FFT
Weighting Rectangular, Hamming, Hanning and Blackman-Harris
Amplitude Display 1, 2, 5, 10dB/Div
Memory 10 waveforms and settings saved and recall
Overload protection 1000VDC or AC peak
Accuracy ±(0.75% + 10d) 50Hz to 1KHz
Overload protection 1000VDC or AC peak
Overload Protection 250V DC or AC peak
Capacitance Range 60nF to 300µF
Other measurements Diode Test Accuracy ±2%
Continuity Buzzer will sound < 60W
dBm with reference impedances of 2, 4, 8, 16, 50, 75, 93, 110, 125, 135, 150, 300, 600, 900, 1K or 1.2KW
High Current To 600A with external current Clamp
Temperature (with Probe) To 600ºC (1112ºF)
General Specifications Size 8.3" (H) x 4.2" (W) x 2.2" (D)
Power 9VDC @ 1A AC/DC adapter, 7.2V NIMH rechargeable battery pack
Standard accessories AC/DC adapter, User's manual, Scope probe (2), Holster, Test Leads, USB cable and software
Optional accessories (Not Included): Battery pack, Temperature adapter, Clamp-on current probe, Carrying Bag and USB flash memory
*This item is BRAND NEW - not refurbished. It comes with all manufacturer supplied accessories, and full manufacturer's USA warranty.
YOU CAN CHECK SHURE'S WEB SITE FOR DETAILED ITEM SPECIFICATIONS.
Please email if you have any questions.
PLS EMAIL ME WITH ANY QUESTIONS OR IF YOU NEED INFO OR ADDITIONAL PICS !
WILL ACCECPT CASH FOR LOCAL PICK UP PURCHASES ONLY.
PLS CONTACT US FOR ANY FURTHER QUESTIONS YOU MIGHT HAVE.
INSURACE IS OPTIONAL AND ALWAYS RECOMMENDED.
