Epson 14.318MHZ SG531P dip-8 package crystal oscillator
STYLE: OUTPUT ENABLE PIN OSCILLATOR
FREQUENCY = 14.318MHz * OUTPUT = TTL * Vcc = 5VDC
PACKAGE = 1/2 SIZE 4-PIN PLASTIC PKG * LOAD = 10 TTL
[ THERE ARE 20 LOTS OF 35 CRYSTAL OSCILLATORS EACH AVAILABLE FOR PURCHASE! ]
Image Hosted by GHz_Designs http://
UP FOR SALE ARE ONE TO TWENTY BRAND NEW 35 PIECE LOTS OF NEW UNUSED EPSON SEIKO MODEL SG-531P 14.3180MHz
1/2 SIZE PLASTIC PACKAGED TTL CRYSTAL OSCILLATORS WITH ENABLE AND A 10TTL FANOUT! THESE COME IN A STANDARD
ESD SAFE IC TUBE WITH 35 OSCILLATORS PER TUBE. THESE ARE EQUAL TO 4 X 3.58MHz (COLOR BURST) AND ARE USED WITH
ALOT OF SYNTHISIZER CHIPS TO GENERATE DIFFERENT CLOCK RATES USED ON MOTHERBOARDS AND AS THE CLOCK SOURCE
FOR SERIAL CHIPS TO GENERATE THE BAUD RATE. WITH IT'S ENABLE LINE THE OUTPUT CAN GO TO OPEN OR HIGH IMPEDANCE
SO AS TO ALLOW SWITCHING BETWEEN CLOCKS IN A MULTI CLOCK SYSTEM, IF ALL YOU DID WAS SWITCH BETWEEN OUTPUTS
YOU WOULD STILL HAVE THE OSCILLATOR GENERATING THE FREQUENCY AND IT WOULD STILL GET INTO THE VCC AND GROUND
LINES WHICH WOULD CAUSE ALOT OF PROBLEMS, SO IT'S TURNED OFF/ON TO STOP ANY OF THE ABOVE MENTIONED PROBLEMS.
*** DUE TO THE IC TUBES LENGTH WE MUST PURCHASE A MAILING TUBE ***
*** COST IS A ONE TIME CHARGE OF $1.49 WHICH IS INCLUDED IN THE S&H ***
*** THUS SAVING YOURSELF SOME OF YOUR HARD EARNED MONEY! ***
THANKS FOR LOOKING & GOOD LUCK!
