Used ballscrew support nsk japan WBK10-11 round type
iMokCha Industrial Automation Surplus Store
Used Ballscrew Support NSK Japan WBK10-11 Round Type
This unit appears to be in good condition and was disassembled from a working unit. The unit consist of (1) set Angular Ball Bearing 7000ATYDFC8P5, oil seals on both ends, and a spacer ring. This is a perfect match for standard size ballscrews with a Ø12mm Shaft diameter (and some cases for Ø10mm Shaft with a lead of 4mm).
* Ballscrew Support Unit Round Type NSK Ref#: WBK10-11
* Product Cross Reference: THK Support Unit FK-10
* Overall Size: 42mm x 42mm x 27 mm long
* Drop-in Hole Size: Ø 34 g6 mm x 17 mm long
* Mounting screw: 4x M4 on PCD 42mm
This unit does not come with a locknut for tightening onto the standard end of the ballscrew.
Product Attributes described above are to our best of knowledge. Please contact us if you require further information.
Please also check out manufacturer's website http:// for further information on this product.
You can also find the specification and detailed dimension on our server. Click Here.
We've also included a guide for selecting the ballscrew support. Click Here.
Keywords: BALLSCREW ANGULAR BALL BEARING SUPPORT ROUND TYPE
