Lot of 5 pilz pze X4 24VDC 4N/o expander modules 774585
Lot of 5 Pilz PZE X4 24VDC 4n/o Expander Modules 774585
This is a lot of 5 Pilz PZE X4 4n/o Expander Modules, Identification #774585.
* Application options: Instantaneous contact expansion
* Number of instantaneous safety contacts: 4
* Number of delayed safety contacts: -
* Number of auxiliary contacts: -
* Number of semiconductor outputs: -
* Max. current at DC1: 8,0 A
* Width dimension (inches): 0.89"
* Height dimension (inches): 3.43"
* Depth dimension (inches): 4.76"
* Approvals: UL/cUL , CCC , BG
* Terminal type: Screw terminal
+ Positive-guided relay outputs:
+ 4 safety contacts (N/O), instantaneous
+ See order reference for unit types
The unit meets the requirements of EN 60204-1 and IEC 60204-1.
The contact expander module is used to increase the number of contacts available on a base unit. Base units are all
The category that can be achieved in accordance with EN 954-1 depends on the category of the base unit. The contact expander module may not exceed this.
The unit meets the following safety requirements:
+ The safety function remains effective in the case of a component failure.
+ Earth fault in the input circuit: The output relays de-energize and the safety contacts open.
