LM324N quad op-amp 14 pin dil - LM324 opamp amplifier
Quad Op-Amp in a 14 PIN DIL package made by ST
(an alternative manufacturer of equal quality may be supplied)
These device are ROHS compliant.
LM324 Low Power Quad Operational Amplifiers
Automatic discount is given for multiple purchases.
The LM324 series consists of four independent, high gain, internally frequency compensated operational amplifiers
which were designed specifically to operate from a single power supply over a wide range of voltages. Operation from
split power supplies is also possible and the low power supply current drain is independent of the magnitude of the
Application areas include transducer amplifiers, DC gain blocks and all the conventional op amp circuits which now
can be more easily implemented in single power supply systems. For example, the LM324 series can be directly operated off of the standard
a5V power supply voltage which is used in digital systems and will easily provide the required interface electronics without requiring the additional 15V power supplies.
In the linear mode the input common-mode voltage range includes ground and the output voltage can also
swing to ground, even though operated from only a single power supply voltage
The unity gain cross frequency is temperature compensated
The input bias current is also temperature compensated
Eliminates need for dual supplies
Four internally compensated op amps in a single package
Allows directly sensing near GND and VOUT also goes to GND
Compatible with all forms of logic
Power drain suitable for battery operation Features
Internally frequency compensated for unity gain
Wide bandwidth (unity gain) 1 MHz (temperature compensated)
Wide power supply range: Single supply 3V to 32V or dual supplies 1.5V to g16V
Very low supply current drain (700 mA)Ãessentially independent of supply voltage
Low input biasing current 45 nA (temperature compensated)
Low input offset voltage 2 mV and offset current 5 nA
Input common-mode voltage range includes ground
Differential input voltage range equal to the power supply voltage
Large output voltage swing 0V to Va b 1.5V
