Ideal 61-830 voltage monitor, datalogger
Internet Security By ControlScan Internet Security By ControlScan Internet Security By ControlScan Internet Security By ControlScan
* Logs only those voltage events that affect equipment performance
- No need to review unimportant voltage events
- Select standard, choose nominal voltage, set time/date
* Captures sags, swells, impulses and harmonics
- Displays time and severity of events
* Easy, on-screen review of events
- No PC, software or cable required!
* Plugs directly into outlet
- Includes adapters for US, UK, China/Australia and Europe
* Works on 100–240 volt single phase circuits
Voltage Performance Monitor Display Screens:
Professional and accurate voltage analysis made easy
Through easy-to-navigate setup, select from a menu of pre-set standards, plug it into the outlet and watch the unit capture and log voltage events. All the information you need is at your fingertips presented on a super-bright OLED display. Using the Voltage Performance Monitor (VPM) is the easiest way to know the reliability of your voltage.
* Real-time TRMS voltage, frequency and harmonics monitoring
* Logs voltage, sags, swells and impulses
* Measures %THD and logs periods over 3% (line to neutral)
* Selectable thresholds based on the most accepted international standards, defaults to ITIC*
* Custom programmable event thresholds
* Monitor voltage near sensitive equipment
* Installation and Service Technicians
* Monitor voltage at point of equipment connection
* Eliminate guesswork on service calls
* Building Maintenance Technicians
* Identify voltage caused equipment failures
* Eliminate unnecessary warranty costs
* Hospital/IT Maintenance Engineers
* Monitor voltage quality to critical equipment
See voltage through the eyes of your equipment
Poor voltage quality is expensive.
When a voltage problem is suspected, the first approach has been to place an analyzer on the main service. This approach misses problems at the branch level. The VPM works where symptoms occur—at the point where equipment is connected. Poor voltage quality increases facility expenses, warranty costs and downtime plus shortens the life of equipment. The IDEAL VPM identifies voltage conditions that can damage equipment or cause equipment failure.
Equipment is designed to handle varying voltage within a specified range. Voltage events become a concern when they exceed designed tolerances. VPM only captures events that go beyond internationally recognized tolerances, specifically those that are likely to cause equipment problems. Now you have the ability to determine if a failure is related to a voltage event that originated from a utility or other nearby source. You can also determine if voltage is stable enough to add sensitive equipment.
Harmonics are the components of voltage distortion. Distortion of the voltage sine wave is measured as total harmonic distortion. A small amount of distortion will not affect equipment performance. Higher levels of distortion will cause many equipment problems. On branch circuits, levels of harmonics greater than 5%–8% associated with equipment problems need further investigation.
Standards and Event Thresholds
Models, Options, & Accessories
Continuous (128 samples per cycle)
