Asi-192 adf antenna simulator
New in Box. Left on the Shelf and forgotten. Regular Price is $6150
The ASI-192 ADF Antenna Simulator is used in conjunction with the ASI-192 (477V-2) for testing the Collins DF203/206 ADF Systems. The ASI-192 can also be used in conjunction with a Collins 477V-1 to test the DF-202G ADF system.
The ASI-192 provides simulated loop and sense signals to the ADF receiver. Relative direction of the simulated signal is controlled by the front panel knob geared to a pointer on a 360° scale. Corresponding bearing from the receiver is displayed on the radio compass bearing indicator.
